Description
STANDARD GEN 6
New generation with high efficacy at typical >152lm/W, general lighting, directional source delivering high lumen efficacy from the largest selection of Light Emitting Surface (LES), operating power range, and color quality.
TIONS
- Retail/Hospitality/Commercial
- Track/Spot/Bulb
- Architectural/Museums/Exhibits
- Roadway/Parking/Tunnel Lighting
- High/Low Bay
- Canopy/Awning/Wall Pack
FEATURES
- Typical efficacy >152 LPW, 3000K 90CRI, highest reach 184LPW
- Complete LES and Lumen outputs
- AccuWhiteTM Color rendering to 97CRI typ.
- SensusTM and Xtreme SensusTM Pure White
- UL and IEC qualified
- Widest range of CCT/CRI combinations
BENEFITS
- Enhanced efficacy reduces power consumptions
- Source optimized for beam characteristics and optics selection
- Sources to achieve highest color rendering and optimum appearance
- Pure white color rendering with enhanced color saturation
- Pre-certified to fast-tracked fixture certifications
| Product Image | Product Family | LES (mm) | Substrate Size (mm) | Power Range (W) | Flux Range @ 3000K 90CRI |
|---|---|---|---|---|---|
 |
CXM-4 | 4.5 | 13.5 * 13.5 | 4 ~ 14.5 | 475 ~ 1330 |
 |
CXM-6 | 6.3 | 13.5 * 13.5 | 5 ~ 15 | 690 ~ 1655 |
 |
CLM-9 | 9.8 | 13.5 * 13.5 (TC) 15.0 * 15.0 (TA) |
8.2 ~ 29 | 1205 ~ 3375 |
 |
CXM-9 | 9.8 | 13.5 * 13.5 (TC) 15.0 * 15.0 (TA) |
12 ~ 37.4 | 1710 ~ 4445 |
 |
CXM-11 | 11.6 | 19.0 * 19.0 (TC) 18.5 * 18.5 (TA) |
14.5 ~ 44.5 | 2185 ~ 5245 |
 |
CIM-14 | 14.5 | 19.0 * 19.0 | 14.9 ~ 44.5 | 2200 ~ 5280 |
 |
CLM-14 | 14.5 | 19.0 * 19.0 | 16.4 ~ 58.2 | 2480 ~ 6945 |
 |
CXM-14 | 14.5 | 19.0 * 19.0 (TC) 18.5 * 18.5 (TA) |
24 ~ 67.9 | 3450 ~ 7935 |
 |
CGM-14 | 14.5 | 19.0 * 19.0 | 30 ~ 83.1 | 4285 ~ 9855 |
 |
CXM-18 | 17.5 | 28.0 * 28.0 | 26.5 ~ 84 | 4085 ~ 10620 |
 |
CIM-22 | 22.0 | 28.0 * 28.0 | 33 ~ 98 | 5105 ~ 12250 |
 |
CLM-22 | 22.0 | 28.0 * 28.0 | 34.5 ~ 117 | 5485 ~ 15360 |
 |
CXM-22 | 22.0 | 28.0 * 28.0 | 52 ~ 177 | 8100 ~ 21060 |
 |
CGM-22 | 22.0 | 28.0 * 28.0 | 81 ~ 195 | 11940 ~ 24360 |
 |
CXM-32 | 32.8 | 38.0 * 38.0 | 120 ~ 310 | 18720 ~ 39300 |
